PITBUL-LED-PLUS-CG-4400-4K, IP66

IP66
PITBUL-LED-PLUS-CG-4400-4K, IP66

Product type: 051895

Item number: 42630

Robust metal linear luminaire designed for demanding industrial environments. Body made of powder coated steel sheet (RAL 9016) - alternatively stainless steel AISI304 or AISI316. Cover made of opal tempered safety glass guaranteeing excellent homogeneity of illumination and glare reduction. Equipped with high quality electronic components guaranteeing high efficiency up to 157 lm/W and a lifetime of 100,000 h. It is characterized by high resistance to splash water and dust IP66. Suitable for ambient temperatures from -20°C to +60°C. Silicone-free - certified according to VDMA 24364. Mounting with ceiling brackets, positionable brackets or pipe brackets allows a wide variation of use. Designed for attachment or hanging mounting.
Dimensional diagram
Download catalogue sheet
Specifications
Dimensions

A x B x C

1250 mm x 245 mm x 100 mm

Net weight

11,78 Kg

Light technical data

Luminous flux of the luminaire

4034 lm +/-10%

Luminaire efficiency

155 lm/W

CRI

≥80

MacAdam step

3

Luminaire beam angle

Very wide beam >80°

Correlated color temperature

4000 K

Electrical data

Total consumption

26 W +/- 10%

Rated operational voltage AC

220-240 V

Frequency range

50-60 Hz

Rated operational voltage DC

220-240 V

Control method

ON/OFF

Insulation class

I

Number of luminaires per circuit breaker B10A

22

Number of luminaires per circuit breaker B16A

37

Number of luminaires per circuit breaker C10A

38

Number of luminaires per circuit breaker C16A

62

Momentum current

23 A

Mechanical data

IP classification

IP66

IK classification

IK10+

Warranty

5 years

Operating temperature

-20°C≤ta≤60°C

Certification

EAC

EAES N RU E-CZ.PA01.B.01682/21

Materials

Material of the body

painted steel sheet

Body colour

white RAL 9016

Cover material

CG - clear tempered safety glass

Packaging

Barcode (EAN)

8592040295635

Number of pieces per pallet

15 pcs

Gross weight

12,48 kg

Polar diagram
Fotometrické údaje
Accessories
Hinge screw DIN 580 M8 - eye

Item number: 2038

PITBUL/SALUKA boom for boom diameter 50 mm (1 piece) AISI 304

Item number: 3590

PITBUL boom set (2 pcs)

Item number: 4317

PITBUL 4x18W suspended ceiling frame set

Item number: 4319

PITBUL 4x36W suspended ceiling frame set

Item number: 4321

Set of stainless steel ceiling handles PITBUL (2 pcs) AISI 304

Item number: 4811

PITBUL 18W suspended ceiling frame set

Item number: 4318

PITBUL 36W suspended ceiling frame set

Item number: 4320

PITBUL 58W suspended ceiling frame set

Item number: 4322

PITBUL 4x58W suspended ceiling frame set

Item number: 4323

PITBUL-LED-PLUS-CG-4400-4K, IP66

Product type: 051895  Item number: 42630

Robust metal linear luminaire designed for demanding industrial environments. Body made of powder coated steel sheet (RAL 9016) - alternatively stainless steel AISI304 or AISI316. Cover made of opal tempered safety glass guaranteeing excellent homogeneity of illumination and glare reduction. Equipped with high quality electronic components guaranteeing high efficiency up to 157 lm/W and a lifetime of 100,000 h. It is characterized by high resistance to splash water and dust IP66. Suitable for ambient temperatures from -20°C to +60°C. Silicone-free - certified according to VDMA 24364. Mounting with ceiling brackets, positionable brackets or pipe brackets allows a wide variation of use. Designed for attachment or hanging mounting.

Parameters

A x B x C: 1250 mm x 245 mm x 100 mm; Hmotnost netto: 11,78Kg; Světelný tok svítidla: 4034lm +/-10%; Měrný výkon svítidla: 155lm/W; CRI: ≥80; MacAdam: 3; Vyzařovací úhel svítidla: Velmi široký paprsek >80°; Teplota chromatičnosti: 4000K;Příkon svítidla: 26W +/- 10%; Vstupní napětí AC: 220-240V; Vstupní frekvence AC: 50-60Hz; Vstupní napětí DC: 220-240V; Způsob ovládání: ON/OFF; Třída izolace: I; Počet svítidel na jistič B10A: 22; Počet svítidel na jistič B16A: 37; Počet svítidel na jistič C10A: 38; Počet svítidel na jistič C16A: 62; Náběhový proud: 23A;IP kód: IP66; Kód ochrany proti mechanickým nárazům: IK10+; Záruka: 5 let; Provozní teplota: -20°C≤ta≤60°C;EAC: EAЭС N RU Д-CZ.PA01.B.01682/21;Materiál tělesa: ocelový lakovaný plech; RAL tělesa: bílá RAL 9016; Materiál krytu: CG - čiré tvrzené bezpečnostní sklo;Čárový kód (EAN): 8592040295635; Počet kusů na paletě: 15 ks; Hmotnost brutto: 12,48 kg;
